Fflange Threaded

Fflans edau

Mae'r flanges threaded yn nodweddiadol am beidio â defnyddio weldio ar gyfer eu gosod, sy'n caniatáu cynulliad hawdd a chyflym. Nid yw'n ddoeth defnyddio flanges wedi'u threaded mewn cwndidau lle mae amrywiadau tymheredd sylweddol, oherwydd oherwydd ehangu'r bibell, gellir creu colledion trwy'r edafu ar ôl cyfnod o waith.

Flange Edau ANSI 150 Lb. (Edafedd&"TH &")

Enwol pibell maint	Fflans Fflans				Hwb gwddf	Wedi'i godi wyneb Uchafbwynt	Templed drilio Driliau			Tua. pwysau Pwysau tua.
	D.	J.	b	h	m	g	Rhif	l	k	Kg
Diamedr enwol	mm. modfedd	mm. modfedd	mm. modfedd	mm. modfedd	mm. modfedd	mm. modfedd	Rhif	mm. modfedd	mm. modfedd	Punnoedd
1/2 ″	88.9 3 1/2	Nid oes angen Bore cownter mewn 150 Lb. FLANGES THREADED Ar flanges 150 Lb THREADED, nid oes angen lledu ceg	11.1 7/16	15.9 5/8	30.2 1 3/16	34.9 1 3/8	4	15.9 5/8	60.3 2 3/8	0.5 1
3/4 ″	98.4 3 7/8		12.7 1/2	15.9 5/8	38.1 1 1/2	42.9 1 11/16	4	15.9 5/8	69.8 2 3/4	0.9 2
1 "	107.9 4 1/4		14.3 9/16	17.5 11/16	49.2 1 15/16	50.8 2	4	15.9 5/8	79.4 3 1/8	0.9 2
1 1/4 ″	117.5 4 5/8		15.9 5/8	20.6 13/16	58.7 2 5/16	63.5 2 1/2	4	15.9 5/8	88.9 3 1/2	1.4 3
1 1/2 ″	157.0 5		17.5 11/16	22.2 7/8	65.1 2 9/16	73.0 2 7/8	4	15.9 5/8	98.4 3 7/8	1.5 3.3
dau "	152.4 6		19.1 3/4	25.4 1	77.8 3 1/16	92.1 3 5/8	4	19.0 3/4	120.6 4 3/4	2.3 5.1
2 1/2 ″	177.8 7		22.3 7/8	28.6 1 1/8	90.5 3 9/16	104.8 4 1/8	4	19.0 3/4	139.7 5 1/2	3.7 8.1
3 "	190.5 7 1/2		23.8 15/16	30.2 1 3/16	107.9 4 1/4	127.0 5	4	19.0 3/4	152.4 6	4.2 9.2
3 1/2 ″	215.9 8 1/2		23.8 15/16	31.7 1 1/4	122.2 4 13/16	139.7 5 1/2	8	19.0 3/4	177.8 7	5.3 11.7
4 "	228.6 9		23.8 15/16	33.3 1 5/16	134.9 5 5/16	157.2 6 3/16	8	19.0 3/4	190.5 7 1/2	5.9 13
5 "	254 10		23.8 15/16	36.5 1 7/16	163.5 6 7/16	185.7 7 5/16	8	22.2 7/8	215.9 8 1/2	7 15.4
6 ″	279.4 11		25.4 1	39.7 1 9/16	192.1 7 9/16	215.9 8 1/2	8	22.2 7/8	241.3 9 1/2	8.4 18.5
8 ″	342.9 13 1/2		28.6 1 1/8	44.4 1 3/4	246.1 9 11/16	269.9 10 5/8	8	22.2 7/8	298.4 11 3/4	13 28.6
10 ″	406.4 16		30.2 1 3/16	49.2 1 15/16	304.8 12	323.8 12 3/4	12	25.4 1	361.9 14 1/4	19.5 43
12 ″	482.6 19		31.8 1 1/4	55.6 2 3/16	365.1 14 3/8	381.0 15	12	25.4 1	431.8 17	29.5 64.9
14 ″	533.4 21		34.9 1 3/8	57.1 2 1/4	400.0 15 3/4	412.7 16 1/4	12	28.6 1 1/8	476.2 18 3/4	41 90
16 ″	596.9 23 1/2		36.5 1 7/16	63.5 2 1/2	457.2 18	469.9 18 1/2	16	28.6 1 1/8	539.7 21 1/4	47 103.4
18 ″	635.0 25		39.7 1 9/16	68.3 2 11/16	504.8 19 7/8	533.4 21	16	31.7 1 1/4	577.8 22 3/4	59 130
ugain "	698.5 27 1/2		42.9 1 11/16	73.0 2 7/8	558.8 22	584.2 23	20	31.7 1 1/4	635.0 25	75 165
24 ″	812.8 32		47.6 1 7/8	82.5 3 1/4	663.6 26 1/8	692.1 27 1/4	20	34.9 1 3/8	749.3 29 1/2	100 220

Flange Edau ANSI 300 Lb (Threaded" TH")

Enwol pibell maint	Fflans Fflans					Hwb gwddf	Wedi'i godi wyneb Uchafbwynt	Templed drilio Driliau			Tua. pwysau Pwysau tua.
	D.	J.	b	h	x	m	g	Rhif	l	k	Kg
Diamedr enwol	mm. modfedd	mm. modfedd	mm. modfedd	mm. modfedd	mm. modfedd	mm. modfedd	mm. modfedd	Rhif	mm. modfedd	mm. modfedd	Punnoedd
1/2 ″	95.2 3 3/4	23.6 0.93	14.3 9/16	22.2 7/8	15.9 5/8	38.1 1 1/2	34.9 1 3/8	4	15.9 5/8	66.7 2 5/8	0.9 2
3/4 ″	117.5 4 5/8	28.95 1.14	15.9 5/8	25.4 1	15.9 5/8	47.6 1 7/8	42.9 1 11/16	4	19.05 3/4	82.5 3 1/4	1.4 3
1 "	123.8 4 7/8	35.8 1.41	17.5 11/16	27.0 1 1/16	17.5 11/16	54.0 2 1/8	50.8 2	4	19.05 3/4	88.9 3 1/2	1.4 3
1 1/4 ″	133.35 5 1/4	44.45 1.75	19.05 3/4	27.0 1 1/16	20.6 13/16	63.5 2 1/2	63.5 2 1/2	4	19.05 3/4	98.4 3 7/8	1.9 4, .2
1 1/2 ″	155.6 6 1/8	50.5 1.99	20.6 13/16	30.2 1 3/16	22.2 7/8	69.8 2 3/4	73.0 2 7/8	4	22.2 7/8	114.3 4 1/2	2.8 6.2
dau "	165.1 6 1/2	63.5 2.50	22.2 7/8	33.3 1 5/6	28.6 1 1/8	84.1 3 5/6	92.1 3 5/8	8	19.05 3/4	127.0 5	3.3 7.3
2 1/2 ″	190.5 7 1/2	76.2 3.00	25.4 1	38.1 1 1/2	31.7 1 1/4	100.0 3 15/16	104.8 4 1/8	8	22.2 7/8	149.2 5 7/8	4.6 10.1
3 "	209.55 8 1/4	92.2 3.63	28.6 1 1/8	42.9 1 11/16	31.7 1 1/4	117.5 4 5/8	127 5	8	22.2 7/8	168.3 6 5/8	6.3 13.9
3 1/2 ″	228.6 9	104.9 4.13	30.2 1 3/16	44.4 1 3/4	36.5 1 7/16	133.35 5 1/4	139.7 5 1/2	8	22.2 7/8	184.15 7 1/4	7.8 17.2
4 "	254.0 10	117.6 4.63	31.8 1 1/4	47.6 1 7/8	36.5 1 7/16	146.05 5 3/4	157.2 6 3/16	8	22.2 7/8	200.0 7 7/8	10.2 22.4
5 "	279.4 11	144.5 5.69	34.9 1 3/8	50.8 2	42.9 1 11/16	177.8 7	185.7 7 5/16	8	22.2 7/8	234.95 9 1/4	12.9 28.4
6 ″	317.5 12 1/2	171.45 6.75	36.5 1 7/16	52.4 2 1/6	46 1 13/16	206.4 8 1/8	215.9 8 1/2	12	22.2 7/8	269.9 10 5/8	17.7 39
8 ″	381.0 15	222.25 8.75	41.3 1 5/8	61.9 2 7/16	50.8 2	260.35 10 1/4	269.9 10 5/8	12	25.4 1	330.2 13	26 57.2
10 ″	444.5 17 1/2	276.35 10.88	47.6 1 7/8	66.7 2 5/8	55.6 2 3/16	320.7 12 5/8	323.8 12 3/4	16	28.6 1 1/8	387.3 15 1/4	37.5 82.5
12 ″	520.7 20 1/2	328.7 12.94	50.8 2	73.0 2 7/8	60.3 2 3/8	374.6 14 3/4	381.0 15	16	31.7 1 1/4	450.8 17 3/4	52 114
14 ″	584.2 23	360.4 14.19	54.0 2 1/8	76.2 3	63.5 2 1/2	425.4 16 3/4	412.7 16 1/4	20	31.7 1 1/4	514.3 20 1/4	74.8 190
16 ″	647.7 25 1/2	411.2 16.19	57.2 2 1/4	82.5 3 1/4	68.3 2 11/16	482.6 19	469.9 18 1/2	20	34.9 1 3/8	571.5 22 1/2	86, 2 165
18 ″	711.2 28	462.0 18.19	60.3 2 3/8	88.9 3 1/2	69.8 2 3/4	533.4 21	533.4 21	24	34.9 1 3/8	628.6 24 3/4	113 250
ugain "	774.7 30 1/2	512.8 20.19	63.5 2 1/2	95.2 3 3/4	73.0 2 7/8	587.4 23 1/8	584.2 23	24	34.9 1 3/8	685.8 27	143 315
24 ″	914.4 36	614.4 24.19	69.9 2 3/4	106.4 4 3/16	82.5 3 1/4	701.7 27 5/8	692.1 27 1/4	24	41.3 1 5/8	812.8 32	215 475
